Guidance Relating to the Rules for the Classification of
FRP Ships
GB-07-E
ICS
APPLICATION OF THE GUIDANCE
This "Guidance relating to rules for the survey and construction of FRP ships" (hereafter called as the Guidance) is prepared with the intent of giving guidelines as to the treatment of the various provisions for items required the unified interpretations and items not specified in details in the Rules, and the requirements specified in the Guidance are to be ap- plied, in principle, in addition to the various provisions in the Rules.
As to any technical modifications which can be regarded as equivalent to any requirements in the Guidance, their flexible application will be prop- erly considered.
APPLICATION OF
"GUIDANCE RELATING TO RULES FOR THE CLASSIFICATION OF FRP SHIPS"
1. Unless expressly specified otherwise, the requirements in the Guidance apply to ships contracts for construction are signed on or after 1 July 2014.
2. The amendments to the Guidance for 2012 and their effective date are as follows;
Effective Date 1 July 2014
No Revision (re-printed)
for which
CONTENTS
CHAPTER 1 GENERAL 1
Section 1 General 1
101.
103.
Application 1
Direct Strength Calculations 1
Section 2 Definitions 2
215.
219.
Bonding 2
Hand Lay-up Method 2
Section 3 Hull Construction and Equipments 2
303.
304.
305.
306.
307.
Passenger Ships 2
Scantlings 2
Hat-type Construction 3
Sandwich Construction 3
Weight of Fibreglass Reinforcements and Thickness of Laminates 3
CHAPTER 2 CLASS SURVEYS 5
Section 1 General 5
101.
Application 5
Section 2 Classification Survey during Construction 5
204.
Inspection during Construction 5
CHAPTER 3 MATERIALS 7
Section 1 General 7
102.
Approval and Manufacturing Control 7
Section 2 FRP Materials 7
202.
203.
204.
206.
209.
Resins 7
Gelcoats 7
Fibre Reinforcements 7
Core for Sandwich Constructions 7
Cores for Moulding 7
Section 3 FRP 8
302.
FRP Specimen Test 8
CHAPTER 4 MOULDING 9
Section 6 Bonding and Fastening 9
602.
Bonding 9
Section 7 Bonded Connections 9
702.
L-joints 9
CHAPTER 5 LONGITUDINAL STRENGTH 11
Section 1 Longitudinal Strength 11
103.
Calculations of Section Modulus of Athwartship Section 11
CHAPTER 7 DECKS 13
Section 2 Minimum thickness of Deck Laminates 13
203.
Deck Load 13
CHAPTER 10 BEAMS 15
Section 1 Beams 15
103.
Section Modulus of Beams 15
CHAPTER 12 WATERTIGHT BULKHEADS 17
Section 2 Construction of Watertight Bulkheads 17
203.
Bulkhead Laminates of Structural Plywood 17
CHAPTER 13 DEEP TANKS 19
Section 2 Bulkhead Laminates of Deep Tanks 19
203.
Bulkhead Laminates of Structural Plywood 19
CHAPTER 18 MACHINERY 21
Section 2 Installation of Propulsion Machinery, Fuel Oil Tank and Earthing 21
202.
Fuel Oil Tanks 21
< ANNEX >
Annex 1 Test and Inspections of FRP Materials for Primary Structures 23
Annex 2 Test and Inspections of Sandwich Constructions Materials 30
Annex 3 Banding Strength Test of Bulkhead Laminates of
Structural Plywood 34
